AC Square frame motors with a choice of options:
- Forced Ventilation
- Feedback
- Terminal Box positions
- Paint Finish
- Thermal Detection
- Mounting Arrangements
- Main Shaft
- Bearings
DC Motors for Industrial Applications
DC Motors from Sicme Motori with a choice of
- Forced ventilation
- Field windings
- Bearings
- Shaft
- Mounting arrangements
- Terminal box positions
- Feedback Provisions
Explosion Proof: C-Series
Explosion Proof: C Series DC Motors
Flameproof DC motors C Series had been expressly designed for a fully reliable operation and in conformity of safety prescriptions as requested by the regulation in force for electrical installations in dangerous environments.
The motors are certified by CESI (Centro Elettrotecnic o Sperimentale Italiano ) according to the Directive 94/9/CE (ATEX) for the following environments:
• Group : II (not mine)
• Category : 2 (high protection)
• Type of explosive atmosphere : G (gas, steams, smokes)
• Execution : EX d II B with class of temperature T 3 for duty from S1 to S9
• Degree of protection : IP55 (according to IEC 34-5 )
Motor design
Standards : IEC 60034 Supply : 3-phase, 1-phase, batteries, Ward-Leonard group, chopper
Insulation : Class H Temperature rise : Class H, F, B
Ambient temperature : -20°C – +40°C
Minimum stocking temperature: -40°C
Maximum working temperature (with derating): 60 °C
Altitude of installation : 1000masl max (up to 4000m asl with derating)
Max. skin temperature : +200°C (class of di temperature T3)
Balancing : class G2,5 (ISO 2373)
Type of cooling : IC411 ( IEC 34-6: self ventilated totally enclosed motor, frame externally cooled)
Degree of protection : IP55 (IEC 34-5)
Mounting : according to IEC 34-7
Main terminal box : at left side, viewed from DE
Options available
Thermoprotectors (NC contact)
PTC thermal protector
Pt100 thermistors
Tachometer (explosion-proof type)
Pulse generator (explosion-proof type)
Anticondensation heater (excluding frame C7)
Tropicalization of windings
Brush wear control device (excluding frame 7)
- Power from 0.16 to 35kW
- Supply Voltage from 110 to 440V
- IIB+IIC certified
- EN60034 Standards, 94/9/EC (ATEX Directive)
- IEC-EX and EAC available
General Purpose P-NP Series
General Purpose P-NP Series
These Sicme Motori DC motors are a benchmark on the market of DC motors, with 50 years of experience, since 1967. All these motors have fully laminated frames and Class H insulation. The whole series comprises 20 shaft heights (80-90-100-112-132-160-180-200-225-280-315-355-400-450-500-560-630-710-800), each one with 3 or more core lengths, thus being one of the most complete on the market today, fully engineered and manufactured in Italy.
The power and speed ranges of the versions with and without compensating windings are generally similar for any given size and armature voltage, but compensation, available for 132 and bigger frame sizes, enhances the performance under conditions of overload or weakened flux. A broad set of standardised windings are available for each size in both versions, which offers a considerable number of winding voltage-speed combinations.
- Power from 0.5 to 2600kW
- Shaft Height from 80 to 800mm
- Fully laminated frame
- All mounting arrangements and cooling systems available
- CSA certification and mark available
- NEMA standards available
- IEC60034 Standards
